VHS to DVD Converter: Transfer Analogue Video to Digital via USB with S-Video and Composite Input Support

This VHS to DVD converter allows you to transfer your analogue video collections—from old VHS tapes and camcorder footage to security camera feeds—directly to your computer via USB. The device solves the common problem of deteriorating tapes and obsolete playback equipment by capturing video in digital formats that can be edited, backed up, and watched on modern screens. It is especially useful for archiving family memories, repurposing video content, or setting up a basic PC-based video surveillance monitor. With support for multiple video systems and two input types, this capture card fits a wide range of analogue sources without needing additional adapters.

Key Features and Build

This compact capture adapter packs practical functionality into a small, USB-powered unit. Its straightforward design prioritises compatibility and ease of use, so you can start digitising your tapes within minutes of unpacking.

USB-Powered Operation

No external power adapter is required. The device draws up to 250mA at 5VDC directly from your computer's USB port, making it portable and convenient for use with laptops as well as desktop PCs. A green LED indicator confirms when the unit is powered and ready.

Video Input and Resolution

The converter offers one S-Video input and one Composite RCA video input. When connected via USB 2.0, it captures full-screen DVD resolution up to 720x480 at 30 fps for NTSC and 720x576 at 25 fps for PAL. With USB 1.1, resolution is reduced to 320x240 (NTSC) or 320x288 (PAL). Adjustable colour controls—brightness, contrast, saturation, hue, and sharpness—let you fine-tune the picture.

Compatibility and Recording Formats

The adapter works with all major worldwide colour television standards, so whether your tapes are in NTSC, PAL, or SECAM, you can capture them without extra converters. It supports a broad range of recording formats to suit different storage and editing needs.

Video System Support

NTSC, PAL, and SECAM are all supported, making this device suitable for use with tapes from different regions. The automatic detection simplifies setup, and the included software handles format conversion as part of the recording process.

Recording Formats and Bit Rate

Recordings can be saved as DV, MPEG-1, MPEG-2, MPEG-4 (with DivX), SVCD, VCD, DVD, AVI, or WMV. The MPEG bit rate is adjustable up to 10000 Kbps, giving you control over file size and quality. This flexibility allows you to create files optimised for archiving, sharing online, or burning to disc.

Included Software and Use Cases

The package includes professional video editing software (Ulead Video Studio 10.0 SE DVD) to help you capture, edit, and author content. Beyond simple tape transfer, the device can also be used for video conferencing or as a security surveillance interface.

Video Editing and Capture

The included Ulead Video Studio 10.0 SE DVD provides tools for editing captured footage, adding transitions, and burning DVDs. A snapshot button lets you save still frames as BMP or JPEG files for photo albums. The resizable video window can be expanded up to full screen for comfortable viewing.

Video Conferencing and Surveillance

By connecting a camcorder or CCTV camera, you can use this adapter for live video conferencing via messaging apps such as NetMeeting, MSN Messenger, Yahoo Messenger, or ICQ. It can also turn your computer into a basic video surveillance monitor when linked to security cameras.

Benefits and Buying Considerations

This converter offers a practical, low-cost way to digitise analogue video without complex setups. Its compact size and USB power make it easy to integrate into existing computer systems.

Reusability and Maintenance

Once digital files are saved to your hard drive, you can edit, copy, and back them up without further use of the original tapes. The device itself requires no ongoing maintenance beyond keeping the USB and video connectors clean.

Why Choose This Product

If you have a collection of VHS tapes, camcorder recordings, or need to capture video from analogue sources, this adapter provides a straightforward solution with good format support and editing software included. Its compatibility with NTSC, PAL, and SECAM makes it a versatile choice for users worldwide.
